CNC, or computer numerical control, machining is a popular manufacturing process that involves using computer-controlled machine tools to cut and shape materials with a high level of precision and accuracy.
With over 65,000 square feet of temperature-, vibration-, and access-controlled machining space and an extensive collection of cutting-edge CNC machines, including several of the largest in the world, Baker Industries is home to one of North America’s most diverse and advanced collections of equipment. We offer a variety of machining operations for metal, plastic, and composite materials, including boring, drilling, milling, tapping, turning, threading, and more. We machine parts and tooling of all sizes, from just a couple of inches to 100+ feet long.
Over the past 30+ years, we have continuously invested in the latest technology from around the globe, growing to become one of the continent’s leading providers of high-quality CNC machining services for a wide variety of industries and applications.
We excel at developing and applying advanced manufacturing solutions to meet the complex needs of our customers and the precise tolerances they demand. We plan and schedule work to meet strict deadlines and tackle some of the industry’s largest and most challenging projects.
Our skilled team of machinists, many of whom have been with the company (and their machines) for more than 20 years, are all programmers and operators, reducing downtime and ensuring that our equipment is operated to its full potential.
Name | Axes | Table Load | X | Y | Z | Features |
---|---|---|---|---|---|---|
Emco MECOF Ecomill | 7 | 3,073 lbs./ft² | 394 | 52 | 98 | Hydrostatic rotary table with a load capacity of 88,185 lbs. |
Emco MECOF Powermill | 5 | 3,073 lbs./ft² | 551 | 236 | 122 | Head changer with 4 heads |
Breton FlyMill HD 1300 2T | 5 | 2,048 lbs./ft² | 140 | 325 | 80 | Heavy duty head equipped with a 286 nm high-speed spindle |
Breton Matrix 1000 2T | 5 | 2,048 lbs./ft² | 100 | 240 | 80 | |
Breton Matrix 1000 2T | 5 | 2,048 lbs./ft² | 100 | 160 | 72 | |
Breton FlyMill 1000 2T | 5 | 2,048 lbs./ft² | 100 | 120 | 55 | |
Breton Matrix 1000 2T | 5 | 2,048 lbs./ft² | 98 | 80 | 39 | |
Breton Matrix 800 2T | 5 | 2,048 lbs./ft² | 80 | 64 | 39 | |
Breton Matrix 800 2T | 5 | 2,048 lbs./ft² | 80 | 64 | 39 | |
Hermle C40 | 5 | 4,400 lbs. | 42 | 42 | 36 | |
Hermle C40 | 5 | 4,400 lbs. | 42 | 42 | 36 | |
Hermle C42 | 5 | 3,086 lbs. | 42 | 42 | 36 | |
Hermle C42 | 5 | 3,086 lbs. | 42 | 42 | 36 | |
Hermle C50 | 5 | 4,400 lbs. | 42 | 42 | 36 | |
Hermle C50 | 5 | 4,400 lbs. | 42 | 42 | 36 | |
Toshiba BTS-130H.R22 | 4 | 42,000 lbs. | 120 | 90 | 63 | Rotary table |
Toshiba BTS-130H.R22 | 4 | 42,000 lbs. | 120 | 90 | 63 | Rotary table |
Parpas BF-150-C 50 HP | 3 | 40,000 lbs. | 120 | 60 | 64 | |
Parpas BF-130 50 HP | 3 | 35,000 lbs. | 107 | 60 | 64 | |
Yama Seiki AWEA LP 5025 | 3 | 30,000 lbs. | 100 | 200 | 48 | |
Parpas BF-120-NC 50 HP | 3 | 30,000 lbs. | 98 | 48 | 56 | |
Yama Seiki AWEA LP 3021 | 3 | 20,000 lbs. | 85 | 120 | 40 | |
DeVlieg Spiramatic Jigmil 4K-72 | 3 | 10,000 lbs. | 72 | 60 | 40 | Rotary table |
MAG Fadal VMC 6535 HTX | 3 | 6,000 lbs. | 65 | 35 | 35 | |
MAG Fadal VMC 6535 HTX | 3 | 6,000 lbs. | 65 | 35 | 35 | |
Yama Seiki AWEA VP 2012 | 3 | 10,000 lbs. | 42 | 42 | 36 | |
Yama Seiki AWEA VP 2012 | 3 | 10,000 lbs. | 42 | 42 | 36 | |
Makino S33L Vertical CNC | 3 | 2,000 lbs. | 40 | 20 | 20 | |
Makino S56 Vertical CNC | 3 | 2,000 lbs. | 40 | 20 | 20 | |
Makino S56 Vertical CNC | 3 | 2,000 lbs. | 40 | 20 | 20 | |
Makino S56 Vertical CNC | 3 | 2,000 lbs. | 40 | 20 | 20 | |
YCM NSV102A | 3 | 2,000 lbs. | 20 | 24 | 24 | |
YCM NSV102A | 3 | 2,000 lbs. | 20 | 24 | 24 | |
YCM NSV102A | 3 | 2,000 lbs. | 20 | 24 | 24 | |
YCM NSV102A | 3 | 2,000 lbs. | 20 | 24 | 24 |
Name | Axes | Table Load | X | Y | Z | Features |
---|---|---|---|---|---|---|
Emco MECOF Ecomill | 7 | 15,003.7 kg/m² | 1001 | 132 | 249 | Hydrostatic rotary table with a load capacity of 88,185 lbs. |
Emco MECOF Powermill | 5 | 15,003.7 kg/m² | 1400 | 599 | 310 | Head changer with 4 heads |
Breton FlyMill HD 1300 2T | 5 | 9,999.2 kg/m² | 356 | 826 | 203 | Heavy duty head equipped with a 286 nm high-speed spindle |
Breton Matrix 1000 2T | 5 | 9,999.2 kg/m² | 254 | 610 | 203 | |
Breton Matrix 1000 2T | 5 | 9,999.2 kg/m² | 254 | 406 | 183 | |
Breton FlyMill 1000 2T | 5 | 9,999.2 kg/m² | 254 | 305 | 140 | |
Breton Matrix 1000 2T | 5 | 9,999.2 kg/m² | 249 | 203 | 99 | |
Breton Matrix 800 2T | 5 | 9,999.2 kg/m² | 203 | 163 | 99 | |
Breton Matrix 800 2T | 5 | 9,999.2 kg/m² | 203 | 163 | 99 | |
Hermle C40 | 5 | 1,995.8 kg | 107 | 107 | 91 | |
Hermle C40 | 5 | 1,995.8 kg | 107 | 107 | 91 | |
Hermle C42 | 5 | 1,399.8 kg | 107 | 107 | 91 | |
Hermle C42 | 5 | 1,399.8 kg | 107 | 107 | 91 | |
Hermle C50 | 5 | 1,995.9 kg | 107 | 107 | 91 | |
Hermle C50 | 5 | 1,995.9 kg | 107 | 107 | 91 | |
Toshiba BTS-130H.R22 | 4 | 19,050.9 kg | 305 | 229 | 160 | Rotary table |
Toshiba BTS-130H.R22 | 4 | 19,050.9 kg | 305 | 229 | 160 | Rotary table |
Parpas BF-150-C 50 HP | 3 | 18,143.7 kg | 305 | 152 | 163 | |
Parpas BF-130 50 HP | 3 | 15,875.7 kg | 272 | 152 | 163 | |
Yama Seiki AWEA LP 5025 | 3 | 13,607.8 kg | 254 | 508 | 122 | |
Parpas BF-120-NC 50 HP | 3 | 13,607.8 kg | 249 | 122 | 142 | |
Yama Seiki AWEA LP 3021 | 3 | 9,071.8 kg | 216 | 305 | 102 | |
DeVlieg Spiramatic Jigmil 4K-72 | 3 | 4,535.9 kg | 183 | 152 | 102 | Rotary table |
MAG Fadal VMC 6535 HTX | 3 | 2,721.6 kg | 165 | 89 | 89 | |
MAG Fadal VMC 6535 HTX | 3 | 2,721.6 kg | 165 | 89 | 89 | |
Yama Seiki AWEA VP 2012 | 3 | 4,535.9 kg | 107 | 107 | 91 | |
Yama Seiki AWEA VP 2012 | 3 | 4,535.9 kg | 107 | 107 | 91 | |
Makino S33L Vertical CNC | 3 | 907.2 kg | 102 | 51 | 51 | |
Makino S56 Vertical CNC | 3 | 907.2 kg | 102 | 51 | 51 | |
Makino S56 Vertical CNC | 3 | 907.2 kg | 102 | 51 | 51 | |
Makino S56 Vertical CNC | 3 | 907.2 kg | 102 | 51 | 51 | |
YCM NSV102A | 3 | 907.2 kg | 51 | 61 | 61 | |
YCM NSV102A | 3 | 907.2 kg | 51 | 61 | 61 | |
YCM NSV102A | 3 | 907.2 kg | 51 | 61 | 61 | |
YCM NSV102A | 3 | 907.2 kg | 51 | 61 | 61 |
We machine a very comprehensive range of materials, including metals, plastics, and some composites. Expand the sections below to see non-exhaustive lists of the materials we most commonly work with. We have extensive experience with and the equipment to handle many exotic, difficult, and volatile materials, including Inconel®, Invar®, titanium, magnesium, and more.
Don’t see what you’re looking for? Get in touch with us today to talk about your project!
Material | Full Name | Other Common Names |
---|---|---|
ABS | Acrylonitrile butadiene styrene | |
ACM | Aluminum composite material | Alupanel, DIBOND, E-PANEL, Signabond |
ASA | Acrylonitrile styrene acrylate | |
ECTFE | Ethylene chlorotrifluoroethylene | |
ETFE | Ethylene tetrafluoroethylene | |
FEP | Fluorinated ethylene propylene | |
FR-4 | Flame-retardant, glass-reinforced epoxy laminate | |
G-10 | High-pressure fiberglass laminate | |
HDPE | High-density polyethylene | |
IPK | Acrylic-polyvinyl chloride | |
LDPE | Low-density polyethylene | |
Nylon | Polyamide | PA |
PAEK | Polyaryletherketone | |
PAI | Polyamide-imide | |
PBT | Polybutylene terephthalate | |
PC | Polycarbonate | |
PCTFE | Polychlorotrifluoroethylene | |
PE | Polyethylene | |
PEEK | Polyetheretherketone | |
PEI | Polyetherimide | ULTEM® |
PEKK | Polyetherketone | |
PET | Polyethylene terephthalate | PETE |
PETG | Polyethylene terephthalate glycol | |
PFA | Perfluoroalkoxy | |
PI | Polyimide | |
PMMA | Poly(methyl methacrylate) | |
POM | Polyoxymethylene | |
PP | Polypropylene | |
PPO | Polyphenylene oxide | |
PPS | Polyphenylene sulfide | |
PPSF | Polyphenylsulfone | PPSU |
PS | Polystyrene | |
PSF | Polysulfone | PSU |
PTFE | Polytetrafluoroethylene | |
PTFE Virgin Unfilled | Polytetrafluoroethylene (unfilled) | |
PU | Polyurethane | PUR, RenShape® |
PVC | Polyvinyl chloride | |
PVDF | Polyvinylidene fluoride | |
UHMWPE | Ultrahigh-molecular-weight polyethylene |
Speak to a CNC machining expert today! Our team is standing by, ready to help answer questions or get started on a quote for your project.
